一、Product Overview：
KODIN 6 series - DE double electrode geomembrane leak detector is an intelligent detection terminal built by Kedian Instruments based on Internet technology.
This instrument is equipped with the Android system, which allows for easy customization of various professional testing solutions based on on-site operations and industry standards;
Equipped with wireless communication function, it can easily achieve remote audio and video data interaction;
The casing incorporates industrial design concepts, and the casing protection adopts a three proof design of waterproof, dustproof, and anti drop, which can adapt to various complex industrial sites.
It can detect leakage points below 0.5m and not less than 6mm under the condition of good conductivity of the covering layer.
二、Technical Specifications：
Receiver Technical Parameters
| Measure voltage range | ±200VDC |
| Positioning accuracy | RTK Centimeter level |
|
Voltage trend |
Manually record the voltage value and generate a voltage line graph |
| Leakage alarm |
When the voltage value shows a positive or negative reversal, an alarm sound will be emitted |
|
Data recording |
Voltage value, latitude and longitude, altitude, remarks, reasons for leakage and pictures |
|
Generate report |
Generate a report with just one click based on the recorded content |
| Supporting protection |
Comes with a protective cover for the chassis, suitable for both handheld and pendant carrying |
| Display screen |
6-inch IPS touch high-definition LCD screen |
|
Working hours |
10-20 hours |
| Weight | 约520gAbout 520g |
Technical parameters of transmitter
|
Output power |
100W |
|
Output voltage |
0~700V |
|
Output current |
0~1000mA |
|
Power supply |
220VAC~240VAC |
|
Safety protection |
Open the output connector cover and turn off the power; The red "STOP" button cuts off power; |
| Overload reminder | When the current is greater than 1000mA and the temperature is greater than 60 ℃, an alarm prompt appears on the screen, and the output voltage needs to be manually reduced |
|
Weight |
About 16kg |
三、Site of use：
四、Standard product packing list：
1. 1 KODIN 6A-DE receiver
2. 1 T × 100 transmitter
3. 1 electrode holder
4. Two electrodes
5. 1 power adapter (10V 2A)
6. 1 AC power cord
7. Two electrode jumper wires
8. Electrode connection extension cable 1 reel
9. One Q9 to 4mm banana head connecting wire
10. 1 Q9 to BNC socket
11. Two 4mm double ended banana extension cords (one red and one black)
12. 1 RTK high-precision antenna
13. 1 USB data cable
14. 1 SIM card ejector pin
15. 2 fuses (250V 5A)
16. Two reference electrodes
-
